Dispersing Agent for Titanium Dioxide / TiO2, Iron Oxide, and Inorganic Pigment Dispersions

Borchi® Gen 1252 is a dispersant for titanium dioxide (TiO2), iron oxide, and other inorganic pigment dispersions in coatings. It provides higher inorganic pigment loading, better tint strength, and improved contrast ratios. This dispersing agent is an APEO- and VOC-free high molecular weight solution. It works well with both inorganic pigments and fillers in water- and solvent-based coating systems.

Borchi® Gen 1252  is especially known for being effective in dispersing TiO2 and iron oxide pigments, resulting in stable dispersions with excellent color development.



Click here to order a free sample or obtain a technical data sheet



Benefits of TiO2 Dispersants

TiO2 pigments are typically used in white coatings due to their bright, white opaque color. This color forms from their ability to scatter light. These pigments extend the life of a coating due to their strength and durability.

Using TiO2 pigments in formulations provides bright white colors and protective properties for coatings. However, it can be difficult for coatings to obtain the full effects of pigments on their own. Many formulators struggle with knowing how to properly disperse TiO2 pigments. Dispersants designed for TiO2 and inorganic pigments are one way to achieve effective dispersions.

Without assistance from dispersants and other additives, pigments may not settle properly. This results in weakened color, pigmentation, and protective properties. Borchi® Gen 1252 wetting and dispersing agent properly disperses inorganic pigments to enhance color and protective properties. It can be used in water- and solvent-based systems.

The reason this dispersing agent works well with TiO2 in particular is because it provides high tint strength and opacity, as well as strong contrast ratios. These characteristics help bring out the best color possible in white pigments.

Improving TiO2 pigment viscosity and long-term dispersion stability can be done with the use of both dispersing and rheology additives. This will result in an even stronger white color in coatings.



TiO2 Dispersant and Rheology Modifier

Viscosity and long-term dispersion stability is achieved when Borchi® Gen 1252 is used with our Borchi® Gel PN rheology modifier. Borchi® Gel PN achieves better viscosity stability than fumed silica for TiO2 dispersions. Benefits of using both products together include outstanding anti-settling properties, improved viscosity variance over time after extended heat age stability, no change in gloss or contrast ratio, high opacity, and strong tint strength.





viscosity stability with dispersing agent for titanium dioxide Borchi Gen 1252 and Borchi Gel PN shear thinning rheology modifier

 Based on formulation for 2-Week, 50° C Stability Test that includes Borchi® Gen 1252, Borchi® Gel PN, and Borchers® AF 1171 defoamer improves viscosity stability with TiO2 pigments





2-Week, 50° C Stability

want to know how to disperse titanium dioxide? A TiO2 dispersant and rheology modifier achieve ideal stability with inorganic pigments

              Control                                                                       1252/PN

Reduced settling and enhanced flow with Borchi® Gen 1252 dispersing agent for TiO2 and Borchi® Gel PN rheology modifier in 75% TiO2 concentration



Benefits of Iron Oxide Dispersants

While known for its effectiveness in TiO2 pigments, Borchi® Gen 1252 also has a strong affinity to opaque iron oxide pigments. These pigments are great for producing red, yellow, and brown colors. They are also known for being durable as they do not easily change color, making them ideal for exterior coatings exposed to sunlight. Proper iron oxide pigment dispersions with Borchi® Gen 1252 result in enhanced color and durability.



Applications

Titanium dioxide uses with this dispersing agent include automotive, industrial, wood, and protective and marine TiO2 applications. It can also be used in printing inks and adhesives.

As a dispersing agent for iron oxide, it is great for use in coatings for concrete, mortar, tile, wood, and stone applications.

Borchi® Gen 1252 has been tested with neutralizers that include AMP-95® from Angus Company.



Resources

Click here for sales tool.

  • Physical Characteristics

    Appearance Liquid, colorless
    Non-volatile content 100 %
    pH 3 – 4 (aqueous solution 10 %)
    Density 1.13 g/cm3, 23 °C
    Viscosity Max. 3,500 mPa.s
    Solvent(s) NA

  • Features

    • Titanium dioxide dispersant that provides high tint strength and contrast ratio
    • Strong affinity to iron oxide pigments resulting in stable dispersions with excellent color development
    • Over 70 % TiO2 and 60 % iron oxide pigment loadings are possible with free-flowing viscosities
    • Long-term dispersion stability can be achieved when combined with Borchi® Gel PN in water-based systems
    • High gloss

  • Applications

    • Coatings
      • Automotive
      • Industrial
      • Architectural
      • Wood
      • Protective and Marine

  • Dosage

    Depending on the pigment grade, the recommended dosage is

    • TiO2: 2-3 %
    • Iron oxides: 5 %

    The exact dosage should be experimentally determined through a ladder study. Borchi® Gen 1252 should be added to the mill base before adding the pigment. Neutralization is required when used in water-based systems as follows, Per 1-part Borchi® Gen 1252:

    • AMP-90®: 0.041
    • AMP-95®: 0.038
    • DMEA: 0.037
    • TEA: 0.041

  • Storage

    Protect from the effects of weather and store at temperatures between 5 and 30 °C. At temperatures below 15 °C turbidity and flocculation may occur. This effect is reversible and does not influence the product efficiency, so warm up to room temperature and mix well before use. Once opened, containers should be resealed immediately after each removal of the product.

  • Safety

    Please refer to our safety data sheet for information relating to product safety.

Registration :
  • Europe : EINECS, EU - REACH (Registered)
  • Switzerland : EINECS
  • USA : TSCA
  • Canada : DSL
  • New Zealand : NZIoC
  • China : IECSC
  • Taiwan : NECI
